Multi Thread Lugnuts
Product Description
Ideal fasteners for heavy duty applications, ensuring a strong and reliable joint in sheet materials – metal or plastic.
Material
Spring steel
Notes
*AP-MN-0380 lugnut comes with a 35.1mm screw with 13mm washer.
| Product Code | Thread | Panel Range | Length | Width | C | E | F | Finish | X | Pricei | Stock | Pack Sizei | No. of Packs |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LNL-4017 | M4 | 0.8 - 4.3 | 16.9 | 15 | 7 | 0.5 | 7 | Zinc Plated | - | i | i | - | Enquire Now |
| LNL-4014 | M4 | 2 - 4 | 14.9 | 10 | 7.3 | 0.6 | 6.5 | Zinc Plated | 6 | £15.00 | i |
100
|
Enquire Now |
| AP-MN-0360 | M5 | 0.4 - 6.1 | 20.8 | 15.2 | 11.3 | 0.6 | 7 | Zinc Silver | 8.6 | £10.00 | i |
100
|
Enquire Now |
| LNL-5002 | M5 | 0.5 - 4 | 19.9 | 14 | 10.2 | 0.6 | 7.5 | Zinc Plated | 8.5 | £17.80 | 27920 |
100
|
|
| LNL-5017 | M5 | 2 - 4.3 | 14.8 | 12 | 6.1 | 0.6 | 5.9 | Zinc Plated | 6.7 | £17.80 | 18200 |
100
|
|
| LNL-6021 | M6 | 0.5 - 4 | 21.3 | 14.8 | 10.5 | 0.8 | 7 | Zinc Plated | 9.8 | £18.50 | i |
100
|
Enquire Now |
| LNL-6023 | M6 | 0.5 - 4 | 24.1 | 16 | 11.5 | 0.8 | 7 | Zinc Plated | - | i | i | - | Enquire Now |
| LNL-6025-ZNB | M6 | 0.8 - 6.8 | 23 | 23.5 | 11.1 | 0.8 | 6.9 | Black Zinc Nickel | 10 | £16.70 | i |
100
|
Enquire Now |
| LNL-6027 | M6 | 0.8 - 4 | 24.3 | 15 | 12.5 | 0.8 | 10 | Zinc Plated | - | i | i | - | Enquire Now |
| AP-MN-0380 | M8 | 0.4 - 6.1 | 24.8 | 18.3 | 11.5 | 1.3 | 9.9 | Zinc Silver | 10.2 | £10.75 | 125 |
25
|
|
| LNL-8024 | M8 | 0.5 - 4 | 24.8 | 17 | 12 | 1 | 9 | Zinc Plated | 10 | £11.75 | i |
50
|
Enquire Now |
| LNL-8026 | M8 | 0.5 - 4 | 25.5 | 17 | 13 | 1 | 11.2 | Zinc Plated | - | £17.50 | i |
50
|
Enquire Now |
| LNL-8028 | M8 | 0.8 - 4 | 28 | 18 | 13 | 1 | 9 | Zinc Plated | - | i | i | - | Enquire Now |
| AP-MN-0550 | M8 | 2.3 - 4.1 | 24.5 | 16.7 | 13.7 | 1 | 8.9 x 10.2 | Zinc Plated | 9.5 | £12.50 | 200 |
100
|
