SHR-HIS Spiral Housing Rings - SHR-HIS-281
Product Description
Internal, Heavy-Duty Snap Ring
These single-turn snap rings are ideal for applications involving high thrust loads.
| Shaft Dia. (In.) Ds | Groove Dia. (Dg and Tol.) | Groove Width (W and Tol.) | Ring Free Dia. (Df and Tol.) | Ring Section (S and Tol.) | Ring Thickness (T and Tol.) | Thrust Load (lbs.) Groove Safety Factor of 2 | Thrust Load (lbs.) Ring Safety Factor of 3 |
|---|---|---|---|---|---|---|---|
| 2.812 | 2.93 (+0.012/-0.0) | 0.104 (+0.006/-0.0) | 2.958 (+0.03/-0.0) | 0.2 (±0.005) | 0.095 (±0.003) | 11727 | 28784 |
